Nplot Document
List of all members.
A Windows.Forms PlotSurface2D control.
Detailed Description
A Windows.Forms PlotSurface2D control. Taylor Polynomials Up: Homework Previous: Submit Contents Test Driver. Program testspline implicit none interface subroutine spline(t,y,x,v) implicit none double. NPlot is a pretty good simple open source 2D plotting API. Unfortunately, the web site is down. I don't know if this is just temporary or not. I haven't heard of any.
Unfortunately it's not possible to derive from both Control and NPlot.PlotSurface2D.
Definition at line 72 of file Windows.PlotSurface2D.cs.Public Member Functions | |
| void | Add (IDrawable p, NPlot.PlotSurface2D.XAxisPosition xp, NPlot.PlotSurface2D.YAxisPosition yp, int zOrder) |
| Adds a drawable object to the plot surface against the specified axes. | |
| void | Add (IDrawable p, int zOrder) |
| Adds a drawable object to the plot surface. | |
| void | Add (IDrawable p, NPlot.PlotSurface2D.XAxisPosition xp, NPlot.PlotSurface2D.YAxisPosition yp) |
| Adds a drawable object to the plot surface against the specified axes. | |
| void | Add (IDrawable p) |
| Adds a drawable object to the plot surface. | |
| void | AddAxesConstraint (AxesConstraint c) |
| Add an axis constraint to the plot surface. | |
| void | AddInteraction (Interactions.Interaction i) |
| Adds and interaction to the plotsurface that adds functionality that responds to a set of mouse / keyboard events. | |
| void | CacheAxes () |
| Remembers the current axes - useful in interactions. | |
| void | Clear () |
| Clears the plot and resets to default values. | |
| void | CopyDataToClipboard () |
| Coppies data in the current plot surface view window to the clipboard as text. | |
| void | CopyToClipboard () |
| Coppies the chart currently shown in the control to the clipboard as an image. | |
| void | DoMouseDown (MouseEventArgs e) |
| All functionality of the OnMouseDown function is contained here. | |
| void | DoMouseMove (MouseEventArgs e, System.Windows.Forms.Control ctr) |
| All functionality of the OnMouseMove function is contained here. | |
| void | DoMouseUp (MouseEventArgs e, System.Windows.Forms.Control ctr) |
| All functionality of the OnMouseUp function is contained here. | |
| void | DoMouseWheel (MouseEventArgs e) |
| All functionality of the OnMouseWheel function is containd here. | |
| void | DoPaint (PaintEventArgs pe, int width, int height) |
| All functionality of the OnPaint method is provided by this function. | |
| void | Draw (Graphics g, Rectangle bounds) |
| Draws the plot surface on the supplied graphics surface [not the control surface]. | |
| delegate void | InteractionHandler (object sender) |
| This is the signature of the function used for InteractionOccurred events. | |
| void | OriginalDimensions () |
| sets axes to be those saved in the cache. | |
| PlotSurface2D () | |
| Default constructor. | |
| delegate void | PreRefreshHandler (object sender) |
| This is the signature of the function used for PreRefresh events. | |
| void | Print (bool preview) |
| Print the chart as currently shown by the control. | |
| void | Remove (IDrawable p, bool updateAxes) |
| Remove a drawable object from the plot surface. | |
| void | RemoveInteraction (Interactions.Interaction i) |
| Remove a previously added interaction. | |
Protected Member Functions | |
| override void | Dispose (bool disposing) |
| Clean up any resources being used. | |
| void | OnInteractionOccured (object sender) |
| Default function called when plotsurface modifying interaction occured. | |
| override void | OnKeyDown (KeyEventArgs e) |
| the key down callback | |
| override void | OnKeyUp (KeyEventArgs e) |
| The key up callback. | |
| override void | OnMouseDown (MouseEventArgs e) |
| Mouse down event handler. | |
| override void | OnMouseMove (MouseEventArgs e) |
| MouseMove event handler. | |
| override void | OnMouseUp (MouseEventArgs e) |
| mouse up event handler. | |
| override void | OnMouseWheel (MouseEventArgs e) |
| Mouse Wheel event handler. | |
| override void | OnPaint (PaintEventArgs pe) |
| the paint event callback. | |
| void | OnPreRefresh (object sender) |
| Default function called just before a refresh happens. | |
Properties | |
| bool | AutoScaleAutoGeneratedAxes |
| When plots are added to the plot surface, the axes they are attached to are immediately modified to reflect data of the plot. | |
| bool | AutoScaleTitle |
| Whether or not the title will be scaled according to size of the plot surface. | |
| System.ComponentModel.IContainer | components |
| bool | DateTimeToolTip |
| When true, tool tip will display x value as a DateTime. | |
| bool | dateTimeToolTip_ = false |
| static PlotContextMenu | DefaultContextMenu |
| Gets an instance of a NPlot.Windows.PlotSurface2D.ContextMenu that is useful in typical situations. | |
| ArrayList | Drawables |
| Gets an array list containing all drawables currently added to the PlotSurface2D. | |
| NPlot.PlotSurface2D | Inner |
| Allows access to the PlotSurface2D. | |
| event InteractionHandler | InteractionOccured |
| Event is fired when an interaction happens with the plot that causes it to be modified. | |
| ArrayList | interactions_ = new ArrayList() |
| KeyEventArgs | lastKeyEventArgs_ = null |
| NPlot.Legend | Legend |
| Gets or Sets the legend to use with this plot surface. | |
| int | LegendZOrder |
| Gets or Sets the legend z-order. | |
| int | Padding |
| Padding of this width will be left between what is drawn and the control border. | |
| PhysicalAxis | PhysicalXAxis1Cache |
| The physical XAxis1 that was last drawn. | |
| PhysicalAxis | PhysicalXAxis2Cache |
| The physical XAxis2 that was last drawn. | |
| PhysicalAxis | PhysicalYAxis1Cache |
| The physical YAxis1 that was last drawn. | |
| PhysicalAxis | PhysicalYAxis2Cache |
| The physical YAxis2 that was last drawn. | |
| IRectangleBrush | PlotBackBrush |
| A Rectangle brush used to paint the plot background. | |
| System.Drawing.Color | PlotBackColor |
| A color used to paint the plot background. | |
| System.Drawing.Bitmap | PlotBackImage |
| An imaged used to paint the plot background. | |
| event PreRefreshHandler | PreRefresh |
| Event fired when we are about to paint. | |
| NPlot.Windows.PlotSurface2D.PlotContextMenu | RightMenu |
| Sets the right context menu. | |
| NPlot.Windows.PlotSurface2D.PlotContextMenu | rightMenu_ = null |
| bool | ShowCoordinates |
| Flag to display a coordinates in a tooltip. | |
| System.Drawing.Drawing2D.SmoothingMode | SmoothingMode |
| Set smoothing mode for drawing plot objects. | |
| string | Title |
| The plot surface title. | |
| Brush | TitleBrush |
| The brush used for drawing the title. | |
| Color | TitleColor |
| Sets the title to be drawn using a solid brush of this color. | |
| Font | TitleFont |
| The font used to draw the title. | |
| Axis | XAxis1 |
| The first abscissa axis. | |
| Axis | XAxis2 |
| The second abscissa axis. | |
| Axis | YAxis1 |
| The first ordinate axis. | |
| Axis | YAxis2 |
| The second ordinate axis. | |
Private Member Functions | |
| void | drawDesignMode (Graphics g, Rectangle bounds) |
| Draw a lightweight representation of us for design mode. | |
| void | DrawHorizontalSelection (Point start, Point end, System.Windows.Forms.UserControl ctr) |
| void | InitializeComponent () |
| Required method for Designer support - do not modify the contents of this method with the code editor. | |
| void | NPlot_PrintPage (object sender, PrintPageEventArgs ev) |
Private Attributes | |
| System.Windows.Forms.ToolTip | coordinates_ |
| NPlot.PlotSurface2D | ps_ |
| System.Collections.ArrayList | selectedObjects_ |
| Axis | xAxis1ZoomCache_ |
| Axis | xAxis2ZoomCache_ |
| Axis | yAxis1ZoomCache_ |
| Axis | yAxis2ZoomCache_ |
Classes | |
| class | Interactions |
| Encapsulates a number of separate 'Interactions'. More... | |
| class | PlotContextMenu |
| Summary description for ContextMenu. More... | |
